2009年全球及中国手机显示屏行业研究报告 >> 水清木华研究中心

　　随着手机基频和内存价格的大幅度下降，手机显示屏成为占手机成本最高的单一零组件。对手机显示屏的研究非常有必要。手机显示屏行业在2006-2007年期间经历了一次产业升级，无论是单色还是彩色STN-LCD的市场大幅度萎缩，不及2004年的10%，TFT-LCD所占的比例超过70%，没有TFT-LCD生产线的厂家度日维艰，于是这些厂家纷纷购买二手TFT-LCD生产线或自建TFT-LCD生产线，这当中包括信利、胜华、凌巨、天马、精电。

　　从2007年底开始，手机显示屏或者说中小显示屏领域发生了一些变化，原本大尺寸TFT-LCD厂家开始加大对中小显示屏的投入，奇美、LG显示、彩晶、华映、群创和友达在中小显示屏领域的收入都成倍增长，这其中奇美、LG显示、彩晶和华映都以CELL的方式出货，而不是模块的方式。主要原因是目前手机显示屏尺寸越来越大，尤其智能手机合黑手机，超过3.5英寸都习以为常，这些通常都是COF封装，需要软板厂配合，同时量少样多，这不是做惯样少量多的大尺寸显示屏厂家们所擅长的。群创是鸿海旗下一员，为集团服务，友达则关注大客户和数码相机领域，这两家多以模块方式出货。这些大尺寸TFT-LCD生产线多是3、4和4.5代线，早已折旧完毕，成本很低。原本预计这些厂家会对传统的手机显示屏厂家造成冲击，现在来看没有，这些厂家多以CELL方式出货，反而依靠传统的手机显示屏厂家为其完成模块工序，形成双赢局面。也使得纬晶、晶创、爱尼亚士之流后起的小厂家仍然有不错的效益。

　　手机显示屏另一个热点就是AM OLED，PM OLED在色彩和分辨率上只是STN-LCD的档次，而其价格远高于STN-LCD。AM OLED是市场焦点。

　　OLED的瓶颈在于其发光材料通电后抗氧化能力极差，需要真空玻璃密封来防止其氧化，这就重走了TFT-LCD的老路。因为OLED是电流型设备，需要比较高的电流驱动，因此需要LTPS TFT基板，目前所有的小尺寸AM OLED都是LTPS TFT基板。因为LTPS TFT基板比传统的A-SI基板的载子迁移速率高100倍。然而LTPS基板制作工序较为繁复，需要较多的光罩和雷射退火的制程，造成throughput较低的状况，若LTPS表面结晶出现缺陷，容易形成Mura,也被认为LTPS基板的应用障碍。a-Si的基板则因制程成熟，容易实现大面积的量产化，因此被视为另一个大型化解决方案，但是a-Si基板仍必须克服TFT起始电压偏移较大与mobility较低等缺点。

　　LTPS注定OLED的成本居高不下，也让OLED的生产线投入规模不次于传统的TFT-LCD，现阶段OLED都是赔本销售，即便是量产，成本依然无法和传统的TFT-LCD比成本，TFT-LCD大多数面板厂已经完成一些旧产线的摊提，同时产量巨大，规模效应很好。LTPS TFT技术只掌握在少数几家大型TFT-LCD厂家中，这些大型TFT-LCD厂家对OLED的态度很关键，除非这些厂家已经完全掌握了OLED的生产诀窍，否则他们不会轻易投入，这就决定现阶段OLED局限在少数几个厂家手中，如三星。AM OLED基本上三星一家独大，这对产业发展很不利。

2007、2008年18家全球主要中小尺寸面板厂家收入排名

With the decreasing prices of mobile phone baseband and memory, mobile phone displays have become the most expensive component for mobile phones. Research on mobile phone display is very necessary. Mobile phone display industry experienced industrial upgrading within the period 2006 to 2007; monochrome and colorful STN-LCD markets shrunk dramatically, much less than 10% in 2004. TFT-LCD accounted for over 70%. Manufacturers without TFT-LCD production lines were in hardship, so they had to buy second-hand TFT-LCD production lines or independently built TFT-LCD production lines, including Truly, Wintek, Giantplus, Tianma and Varitronix.

From the end of 2007, in the field of mobile phone display, especially small and medium-size display, some changes have occurred. Some large-size TFT-LCD manufacturers have begun to increase investment in medium and small display. Chimei, LG Display, Brilliant Crystal, CPT, Innolux and AUO gained increasing income from this field. The shipment of Chimei, LG Display, Brilliant Crystal and CPT was conducted by CELL instead of module. At present, the size of mobile phone (particularly smart phone and illegal mobile phone) displays is often above 3.5 inches, and they are usually packaged by COF with the cooperation of flex-board vendors. The demand for displays focus on various appearances, not on quantity, while large-size display manufacturers always pay attention to the demand for quantity. Innolux is subject to Foxconn Electronics Inc., while AUO is concerned about the key customers and digital camera field; both of them focus on the shipment by module. Their large-size TFT-LCD production lines are mostly 3, 4 and 4.5-generation lines, which have already been depreciated, so the cost is quite low. These large-size TFT-LCD manufacturers do not impact on traditional mobile phone display manufacturers, they conduct shipment by CELL and rely on the latter to complete module process for them, so Wistron, EIO, Aeneas and other small manufacturers gain benefits hereby.

Another hotspot of mobile phone display is AM OLED. PM OLED is the same with STN-LCD in color and resolution, but its price is far higher. AM OLED is the focus in market.

OLED’s disadvantage is that antioxidant capacity of its light-emitting materials is rather poor after being electrified, so it needs vacuum glass seal to prevent oxidation, which is the same with TFT-LCD. OLED is a current-mode device which requires high current drive, so LTPS TFT substrate is essential. Now, all of small-size AM OLEDs are LTPS TFT substrates. The carrier transfer rate of LTPS TFT substrates is 100 times faster than that of traditional A-SI substrates. The manufacturing process of LTPS substrate is very complicated, requiring more mask and laser annealing processes, which leads to low throughput. If there are crystal defects on the surface of LTPS, Mura will arise easily, which is a barrier for the application of LTPS substrate. Due to the perfect process of a-Si substrate, it is easy to carry mass-production. A-Si substrate production is seen as another large-scale solution, but a-Si substrate has disadvantages in initial voltage offset and mobility.

LTPS determines the high cost of OLED. The investment in OLED production line is not lower than that of traditional TFT-LCD. At this stage, OLED is sold at a loss; even in mass production, its cost is still higher than that of traditional TFT-LCD. Most TFT-LCD panel plants have completed amortization of some old production lines, and obtained considerable output as well as good effects. LTPS TFT technology is only mastered by a few big TFT-LCD manufacturers, and their attitude towards OLED is very important, unless they completely grasp OLED manufacturing know-how, they will not invest in OLED. Therefore, OLED is in the charge of a few manufacturers now, such as Samsung. Samsung has overwhelming advantages in AM OLED, which is very unfavorable for the industrial development.

Income Ranking of 18 Small and Medium-size Panel Manufacturers in the World, 2007-2008
