2014-2015年全球及中国汽车HUD（Head-up Display）与仪表产业研究报告 >> 水清木华研究中心

《2014-2015年全球及中国汽车HUD（Head-up Display）与仪表产业研究报告》包含以下内容：
1、全球与中国汽车市场与产业分析
2、全球汽车显示市场与产业
3、汽车HUD发展趋势
4、汽车HUD产业与市场分析
5、汽车仪表产业与市场分析
6、7家典型汽车HUD与仪表厂家研究

HUD（Head-up Display）厂家与汽车仪表（Instrument Cluster）厂家完全重合，因此把它们放在一起研究。HUD可以分为两大类，一类是Windshield上显示，简称W型，另一类是Combiner，简称C型。后者显示内容贫乏，显示对比度很低，实用价值低，其价格低廉，利润不高。可以说C型HUD市场前景黯淡，无论是消费者还是厂家对其都兴趣不大。

W型一般采用HB-LED 做光源Light Source，1.5-3.1英寸TFT-LCD做Picture Source，使用复杂的光学引擎将图像投射在Windshield上，由于环境亮度的变化范围大，HUD 需具有极高的亮度和精确的亮度控制，以形成可轻松读取的图像。显示器将以电子方式纠正任何通过挡风玻璃产生的光学扭曲。W型技术门槛极高，不仅需要精通电子，同样需要精通光学，目前只有和日本和德国厂家能够制造。W型显示对比度高，亮度高，内容丰富，实用性很强，市场前景非常好。

预计2015年W型HUD出货量大约190万Units，C型为70万Units。到2019年W型会大增到1030万套，而C型只有100万套。未来HUD会采用DLP投影加激光二极管（Laser Diode），并且又是Augmented Reality型HUD，能够与ADAS完美配合。这需要采用Quad-core处理器，处理器主频不低于1.5GHz，同时还要有极其复杂的软件系统，其价格可能会超过2000美元。即便如此，因为实用性强，且科技感足，足以得到厂家和消费者的认同。因此市场规模会飞速成长，预计2015年市场规模为431百万美元，2019年达到1420百万美元，是汽车电子领域增长最迅速的产品。

目前HUD主要供应商只有寥寥数家，这些厂家包括日本的Nippon Seiki、Denso；德国的Continental、Bosch等。Denso的主要客户是丰田，Nippon的主要客户是BMW，大约占BMW HUD 80%的订单。Continental主要客户是Benz、BMW和奥迪。

HUD 98%的市场由汽车仪表厂家占据，因此可以把HUD归为汽车仪表行业。HUD也将刺激汽车仪表行业发展。


Global and China Automotive Head-up Display (HUD) and Instrument Cluster Industry Report, 2014-2015 is primarily concerned with the following:

1 Global and China automobile market and industry
2 Global automotive display market and industry
3 Development trends in auto HUD
4 Auto HUD industry and market
5 Instrument cluster industry and market
6 Seven key auto HUD and instrument cluster manufacturers

Now that Head-up Display (HUD) manufacturers and instrument cluster manufacturers are completely coincident, we put and study them together. HUD is divided into two categories: one is display in Windshield (shortened to W-type), the other is Combiner (abbreviated as C type). The latter has poor display content and low practical value, thus leading to lower price and narrow profit. C type HUD market, as it were, has a bleak prospect, which did not appeal to both consumers and manufacturers.

W-type generally applies HB-LED as light source, and 1.5-3.1-inch TFT-LCD as picture source. Meanwhile, using complex optical engine, it projects pictures on the Windshield. Due to the large dynamic range of ambient brightness, extreme luminance and excellent brightness control are required for the HUD (depending on the brightness of the background of the virtual display) in order to produce an image that can be easily read. Any optical distortions through the shield are electronically corrected on the display. W-type has so much higher technical threshold that enterprises are required to master the knowhow of both electronics and optics. At present, only Japanese and German producers have the manufacturing capabilities. W-type display has high contrast ratio and brightness, rich content, and good practicability, hence embracing broad market prospects.

It is expected that in 2015 the shipments of W–type HUD approximate 1.9 million units and C–type 700,000 units. By 2019, W–type will surge to 10.3 million units while C-type will total only 1 million units. In the future, HUD will adopt DLP projection + Laser Diode. Moreover, HUD, or the Augmented Reality-type HUD, can perfectly match up with ADAS, which is required to use Quad-core processor, whose master frequency is not less than 1.5 GHz. At the same time, it needs extremely complicated software system, whose price will probably exceed USD2,000. Even so, it has high practicability and technological content so much so that it can be accepted by manufacturers and consumers. Therefore, the market size will balloon. It is projected that the market size will reach USD431 million in 2015 and USD1.42 billion in 2019, being the fastest-growing product in automotive electronics.

At present, there are only a few key HUD suppliers, including Japan’s Nippon Seiki and Denso and Germany’s Continental and Bosch. Denso’s major client is Toyota whereas Nippon’s client is BMW, which accounted for 80% of BMW HUD orders. Continental’s major clients consist of Benz, BMW, and Audi.

Up to 98% of HUD market is dominated by instrument cluster manufacturers, so HUD can be categorized in instrument cluster industry. HUD will also stimulate the development of instrument cluster industry.
